ホーム /製品/ポリ塩化ビニールのプロフィールの放出ライン/Waste Water Treatment Moving Bed Biofilm Reactor Mbbr Biofilter Media Making Machine HDPE Bio Filter Media Mbbr Carrier Extrusion Manufacturing Machine

Waste Water Treatment Moving Bed Biofilm Reactor Mbbr Biofilter Media Making Machine HDPE Bio Filter Media Mbbr Carrier Extrusion Manufacturing Machine

1セット
MOQ
USD,EUR
価格
Waste Water Treatment Moving Bed Biofilm Reactor Mbbr Biofilter Media Making Machine HDPE Bio Filter Media Mbbr Carrier Extrusion Manufacturing Machine
特徴 ギャラリー 製品の説明 評価とレビュー 見積依頼
特徴
仕様
ハイライト:

HDPE MBBR biofilter media machine

,

wastewater treatment biofilm reactor

,

MBBR carrier extrusion manufacturing
基本情報
起源の場所: Zhangjiagang
ブランド名: LB
証明: CE,ISO
モデル番号: LB-65/33
お支払配送条件
パッケージの詳細: 標準パッケージ
受渡し時間: 45ウォーキング日
支払条件: LC、T/T
供給の能力: 1ヶ月あたりの15セット
製品の説明
Waste Water Treatment Moving Bed Biofilm Reactor MBBR Biofilter Media Making Machine
This HDPE bio filter media MBBR carrier extrusion manufacturing machine is engineered for producing high-quality MBBR carriers used in advanced wastewater treatment systems.
Product Overview
The PVC profile production line is designed for manufacturing various PVC profiles including window and door profiles, ceiling panels, and trunking systems. Custom solutions and molds are developed based on specific drawing requirements.
Processing Workflow
  • PVC powder + additives mixing
  • Material feeding system
  • Twin screw extrusion process
  • Molding and calibration
  • Vacuum forming table
  • Haul-off mechanism
  • Precision cutting system
  • Automated discharge rack
Technical Features
  • Conical twin screw extruder compatible with both PVC powder and granules
  • Advanced degassing system for superior material plasticization
  • High-speed mold technology for increased productivity
  • Optimized for MBBR biofilter media production
Technical Specifications
Model LB180 LB240 LB300 LB600
Max Product Width (mm) 180 240 300 600
Screw Model SJ55/110 SJ65/132 SJ65/132 SJ80/156
Motor Power 22KW 37KW 37KW 55KW
Cooling Water (m³/h) 5 7 7 10
Compressor (m³/h) 0.2 0.3 0.3 0.4
Total Length (m) 18 22 22 25
Production Line Images
Waste Water Treatment Moving Bed Biofilm Reactor Mbbr Biofilter Media Making Machine HDPE Bio Filter Media Mbbr Carrier Extrusion Manufacturing Machine 0 Waste Water Treatment Moving Bed Biofilm Reactor Mbbr Biofilter Media Making Machine HDPE Bio Filter Media Mbbr Carrier Extrusion Manufacturing Machine 1 Waste Water Treatment Moving Bed Biofilm Reactor Mbbr Biofilter Media Making Machine HDPE Bio Filter Media Mbbr Carrier Extrusion Manufacturing Machine 2 Waste Water Treatment Moving Bed Biofilm Reactor Mbbr Biofilter Media Making Machine HDPE Bio Filter Media Mbbr Carrier Extrusion Manufacturing Machine 3 Waste Water Treatment Moving Bed Biofilm Reactor Mbbr Biofilter Media Making Machine HDPE Bio Filter Media Mbbr Carrier Extrusion Manufacturing Machine 4
