Plastic Masterbatch PE/PP/ABS Parrel Twin Screw Water-Ring Pelletizing/Compounding/Recycling/Granulating Extrusion Machine

1セット
MOQ
USD, EUR
価格
Plastic Masterbatch PE/PP/ABS Parrel Twin Screw Water-Ring Pelletizing/Compounding/Recycling/Granulating Extrusion Machine
特徴 ギャラリー 製品の説明 評価とレビュー 見積依頼
特徴
仕様
状態: 新しい
自動グレード: 自動
容量: 400kg/h
プラスチック加工: TPU,EVA,TPEE,PP,PE,PVC,ABS
ネジの設計: ダブルスクリュー
モデル番号: ポンド
モーター: シーメンス
インバータ: ABB
保証: 2年
電気部品: シーメンスまたはシュナイダー
梱包方法: 木製とフィルムパッケージ
納期: 45日
ハイライト:

plastic pelletizing machine with water-ring

,

PE PP ABS twin screw extruder

,

plastic granulating extrusion machine
基本情報
起源の場所: 張jiagang、江蘇
ブランド名: LANGBO
証明: CE, ISO
モデル番号: LB-80156
お支払配送条件
パッケージの詳細: 標準パッケージ
受渡し時間: 60営業日
支払条件: LC、T/T
供給の能力: 毎月10セット
製品の説明
This complete pellet production line efficiently processes PE, PP, and PVC materials through extrusion, strand formation, cooling, and cutting operations. The system transforms raw materials into uniform pellets for convenient storage and excellent market distribution.
Production Process Flow
Raw material + additive → Mixing → Conveying feeding → Hopper feeding → Conical twin screw extruder → Hot face cutting → Cyclone separator → Vibration sieve → Blowing system → Storage hopper → Finished product packing
Technical Specifications
Model Diameter (mm) L/D Speed (rpm) Power (kw) Output (kg/h)
LB40-B 41 24-80 ~600 30~37 100~130
LB52-B 51.4 24-80 ~600 55~75 150~250
LB65-B 62.4 24-80 ~600 90~110 300~400
LB75-B 71 24-80 ~600 132~160 400~500
LB85-B 81 24-80 ~600 220~250 700~800
LB90-B 93 24-80 ~600 280~315 900~1000
LB110-B 110 24-80 ~600 400~450
System Components
Pelletizer Unit
Constructed entirely from AISI 304 stainless steel with pelletizing blades and die made from special alloy steels and coatings tailored to plastic type. Mobile components minimize maintenance requirements, while speed control enables granule size adjustment during operation.
Vibration Sieve
Precisely controls granule size by filtering out oversized and undersized particles. Only properly sized granules proceed to storage silo via air transport system.
Parallel Twin Screw Extruder
  • Heavy load gearbox for reliable continuous operation
  • High precision screw components for optimal material processing
  • Premium electrical components with internationally recognized drive units
  • Simplified temperature setting and monitoring
  • Integrated degassing section for customized processing requirements
Hydraulic Melt Filter Mould
  • 304 stainless steel screens with customized mesh sizes
  • Hydraulic plate or cylinder filter body options available
  • Bronze heating elements for maximum thermal efficiency
Water Tank Tempering System
  • Water circulation for uniform temperature distribution and effective cooling
  • Adjustable strand holders for precise cooling and drying control
  • Advanced manufacturing for robust construction and precise adjustment
Air Knife
High-speed dewatering system for efficient strand moisture removal.
Equipment Gallery
Plastic Masterbatch PE/PP/ABS Parrel Twin Screw Water-Ring Pelletizing/Compounding/Recycling/Granulating Extrusion Machine 0 Plastic Masterbatch PE/PP/ABS Parrel Twin Screw Water-Ring Pelletizing/Compounding/Recycling/Granulating Extrusion Machine 1 Plastic Masterbatch PE/PP/ABS Parrel Twin Screw Water-Ring Pelletizing/Compounding/Recycling/Granulating Extrusion Machine 2 Plastic Masterbatch PE/PP/ABS Parrel Twin Screw Water-Ring Pelletizing/Compounding/Recycling/Granulating Extrusion Machine 3 Plastic Masterbatch PE/PP/ABS Parrel Twin Screw Water-Ring Pelletizing/Compounding/Recycling/Granulating Extrusion Machine 4 Plastic Masterbatch PE/PP/ABS Parrel Twin Screw Water-Ring Pelletizing/Compounding/Recycling/Granulating Extrusion Machine 5
